SoBase Class Reference

The SoBase class is the top-level superclass for a number of class-hierarchies. More...

#include <Inventor/misc/SoBase.h>

Inheritance diagram for SoBase:

Public Member Functions
void	addAuditor (void *const auditor, const SoNotRec::Type type)
virtual void	addWriteReference (SoOutput *out, SbBool isfromfield=FALSE)
void	assertAlive (void) const
const SoAuditorList &	getAuditors (void) const
virtual SbName	getName (void) const
int32_t	getRefCount (void) const
virtual SoType	getTypeId (void) const =0
	Returns the type identification of an object derived from a class inheriting SoBase. This is used for runtime type checking and "downward" casting.
SbBool	isOfType (SoType type) const
	Returns TRUE if the type of this object is either of the same type or inherited from type.
virtual void	notify (SoNotList *l)
void	ref (void) const
void	removeAuditor (void *const auditor, const SoNotRec::Type type)
virtual void	setName (const SbName &newname)
SbBool	shouldWrite (void)
virtual void	startNotify (void)
void	touch (void)
void	unref (void) const
void	unrefNoDelete (void) const

Static Public Member Functions
static void	addName (SoBase *const base, const char *const name)
static SbBool	connectRoute (SoInput *input, const SbName &fromnodename, const SbName &fromfieldname, const SbName &tonodename, const SbName &tofieldname)
static void	decrementCurrentWriteCounter (void)
static SoType	getClassTypeId (void)
	This static method returns the SoType object associated with objects of this class.
static SoBase *	getNamedBase (const SbName &name, SoType type)
static int	getNamedBases (const SbName &name, SoBaseList &baselist, SoType type)
static SbBool	getTraceRefs (void)
static void	incrementCurrentWriteCounter (void)
static void	initClass (void)
	Sets up initialization for data common to all instances of this class, like submitting necessary information to the Coin type system.
static SbBool	read (SoInput *input, SoBase *&base, SoType expectedtype)
static SbBool	readRoute (SoInput *input)
static void	removeName (SoBase *const base, const char *const name)
static void	setInstancePrefix (const SbString &c)
static void	setTraceRefs (SbBool trace)

Protected Types
enum	BaseFlags { IS_ENGINE = 0x01 , IS_GROUP = 0x02 }

Protected Member Functions
	SoBase (void)
virtual	~SoBase ()
virtual SoNotRec	createNotRec (void)
virtual void	destroy (void)
virtual const char *	getFileFormatName (void) const
SbBool	hasMultipleWriteRefs (void) const
virtual SbBool	readInstance (SoInput *input, unsigned short flags)=0
void	writeFooter (SoOutput *out) const
SbBool	writeHeader (SoOutput *out, SbBool isgroup, SbBool isengine) const

Static Protected Member Functions
static uint32_t	getCurrentWriteCounter (void)
static void	staticDataLock (void)
static void	staticDataUnlock (void)

Detailed Description

The SoBase class is the top-level superclass for a number of class-hierarchies.

SoBase provides the basic interfaces and methods for doing reference counting, type identification and import/export. All classes in Coin which uses these mechanisms are descendent from this class.

One important issue with SoBase-derived classes is that they should not be statically allocated, neither in static module memory nor on function's stack frames. SoBase-derived classes must always be allocated dynamically from the memory heap with the new operator.

This is so because SoBase-derived instances are reference counted, and will self destruct on the appropriate time. For this to work, they must be explicitly allocated in heap memory. See the class documentation of SoNode for more information.

Member Enumeration Documentation

BaseFlags

enum SoBase::BaseFlags

protected

This API member is considered internal to the library, as it is not likely to be of interest to the application programmer.

Constructor & Destructor Documentation

SoBase()

SoBase::SoBase ( void )

protected

Constructor. The initial reference count will be set to zero.

~SoBase()

SoBase::~SoBase ( )

protectedvirtual

Destructor. There should not be any normal circumstance where you need to explicitly delete an object derived from the SoBase class, as the reference counting should take care of deallocating unused objects.

See also

unref(), unrefNoDelete()

Member Function Documentation

addAuditor()

void SoBase::addAuditor	(	void *const	auditor,
		const SoNotRec::Type	type )

Add an auditor to notify whenever the object changes in any significant way.

See also

removeAuditor()

addName()

void SoBase::addName ( SoBase *const b, const char *const name )

static

Adds a name<->object mapping to the global dictionary.

addWriteReference()

void SoBase::addWriteReference ( SoOutput * out, SbBool isfromfield = FALSE )

virtual

This method is used during the first write pass of a write action to count the number of references to this object in the scene graph.

Reimplemented in SoFieldContainer, SoBaseKit, and SoGroup.

assertAlive()

void SoBase::assertAlive

(

void

)

const

This API member is considered internal to the library, as it is not likely to be of interest to the application programmer.

There are 4 bits allocated for each SoBase-object for a bitpattern that indicates the object is still "alive". The pattern is changed when the object is destructed. If this method is then called after destruction, an assert will hit.

This is used internally in Coin (in for instance SoBase::ref()) to try to detect when the instance has been prematurely destructed. This is a very common mistake made by application programmers (letting the refcount drop to zero before it should, that is), so the extra piece of assistance through the accompanying assert() in this method to detect dangling references to the object, with subsequent memory corruption and mysterious crashes, should be a Good Thing.

This function is an extension for Coin, and it is not available in the original SGI Open Inventor v2.1 API.

Since

Coin 2.0

connectRoute()

SbBool SoBase::connectRoute ( SoInput * in, const SbName & fromnodename, const SbName & fromfieldname, const SbName & tonodename, const SbName & tofieldname )

static

Connect a route from the node named fromnodename's field fromfieldname to the node named tonodename's field tofieldname. This method will consider the fields types (event in, event out, etc) when connecting.

This function is an extension for Coin, and it is not available in the original SGI Open Inventor v2.1 API.

Since

Coin 2.0

createNotRec()

SoNotRec SoBase::createNotRec ( void )

protectedvirtual

Create a record entry for notification lists.

Reimplemented in SoGroup.

decrementCurrentWriteCounter()

void SoBase::decrementCurrentWriteCounter ( void )

static

This API member is considered internal to the library, as it is not likely to be of interest to the application programmer.

destroy()

void SoBase::destroy ( void )

protectedvirtual

Cleans up all hanging references to and from this instance, and then commits suicide.

Called automatically when the reference count goes to zero.

Reimplemented in SoProto.

getAuditors()

const SoAuditorList & SoBase::getAuditors

(

void

)

const

Returns list of objects auditing this object.

See also

addAuditor(), removeAuditor()

getCurrentWriteCounter()

uint32_t SoBase::getCurrentWriteCounter ( void )

staticprotected

This API member is considered internal to the library, as it is not likely to be of interest to the application programmer.

getFileFormatName()

const char * SoBase::getFileFormatName ( void ) const

protectedvirtual

Returns the class name this object should be written under. Default string returned is the name of the class from the type system.

User extensions nodes and engines override this method to return the name of the extension (instead of "UnknownNode" or "UnknownEngine").

Reimplemented in SoProtoInstance.

getName()

SbName SoBase::getName ( void ) const

virtual

Returns name of object. If no name has been given to this object, the returned SbName will contain the empty string.

getNamedBase()

SoBase * SoBase::getNamedBase ( const SbName & name, SoType type )

static

Returns the object of type, or derived from type, registered under name. If several objects have been registered under the same name with the same type, returns the last one which was registered.

If no object of a valid type or subtype has been registered with the given name, returns NULL.

getNamedBases()

int SoBase::getNamedBases ( const SbName & name, SoBaseList & baselist, SoType type )

static

Returns the number of objects of type type, or derived from type, registered under name.

All matches will also be appended to baselist.

getRefCount()

int32_t SoBase::getRefCount

(

void

)

const

Returns number of objects referring to this object.

getTraceRefs()

SbBool SoBase::getTraceRefs ( void )

static

Return the status of the reference tracing flag.

See also

setTraceRefs()

getTypeId()

SoType SoBase::getTypeId ( void ) const

pure virtual

Returns the type identification of an object derived from a class inheriting SoBase. This is used for runtime type checking and "downward" casting.

Usage example:

void foo(SoNode * node)
{
  if (node->getTypeId() == SoFile::getClassTypeId()) {
    SoFile * filenode = (SoFile *)node;  // safe downward cast, knows the type
  }
}

For application programmers wanting to extend the library with new nodes, engines, nodekits, draggers or others: this method needs to be overridden in all subclasses. This is typically done as part of setting up the full type system for extension classes, which is usually accomplished by using the predefined macros available through for instance Inventor/nodes/SoSubNode.h (SO_NODE_INIT_CLASS and SO_NODE_CONSTRUCTOR for node classes), Inventor/engines/SoSubEngine.h (for engine classes) and so on.

For more information on writing Coin extensions, see the class documentation of the top level superclasses for the various class groups.

Implemented in SoForeignFileKit, SoSTLFileKit, SoShadowCulling, SoShadowDirectionalLight, SoShadowGroup, SoShadowSpotLight, SoShadowStyle, SoProfilerTopEngine, SoNodeVisualize, SoProfilerOverlayKit, SoProfilerTopKit, SoProfilerVisualizeKit, SoScrollingGraphKit, SoProfilerStats, SoCenterballDragger, SoDirectionalLightDragger, SoDragger, SoDragPointDragger, SoHandleBoxDragger, SoJackDragger, SoPointLightDragger, SoRotateCylindricalDragger, SoRotateDiscDragger, SoRotateSphericalDragger, SoScale1Dragger, SoScale2Dragger, SoScale2UniformDragger, SoScaleUniformDragger, SoSpotLightDragger, SoTabBoxDragger, SoTabPlaneDragger, SoTrackballDragger, SoTransformBoxDragger, SoTransformerDragger, SoTranslate1Dragger, SoTranslate2Dragger, SoBoolOperation, SoCalculator, SoComposeMatrix, SoComposeRotation, SoComposeRotationFromTo, SoComposeVec2f, SoComposeVec3f, SoComposeVec4f, SoComputeBoundingBox, SoConcatenate, SoCounter, SoDecomposeMatrix, SoDecomposeRotation, SoDecomposeVec2f, SoDecomposeVec3f, SoDecomposeVec4f, SoElapsedTime, SoFieldConverter, SoGate, SoHeightMapToNormalMap, SoInterpolate, SoInterpolateFloat, SoInterpolateRotation, SoInterpolateVec2f, SoInterpolateVec3f, SoInterpolateVec4f, SoOneShot, SoOnOff, SoSelectOne, SoTexture2Convert, SoTimeCounter, SoTransformVec3f, SoTriggerAny, SoCenterballManip, SoClipPlaneManip, SoDirectionalLightManip, SoHandleBoxManip, SoJackManip, SoPointLightManip, SoSpotLightManip, SoTabBoxManip, SoTrackballManip, SoTransformBoxManip, SoTransformerManip, SoTransformManip, SoProto, SoProtoInstance, SoAppearanceKit, SoBaseKit, SoCameraKit, SoInteractionKit, SoLightKit, SoNodeKitListPart, SoSceneKit, SoSeparatorKit, SoShapeKit, SoWrapperKit, SoAlphaTest, SoAnnotation, SoAntiSquish, SoArray, SoAsciiText, SoBaseColor, SoBlinker, SoBumpMap, SoBumpMapCoordinate, SoBumpMapTransform, SoCacheHint, SoCallback, SoCamera, SoClipPlane, SoColorIndex, SoComplexity, SoCone, SoCoordinate3, SoCoordinate4, SoCube, SoCylinder, SoDepthBuffer, SoDirectionalLight, SoDrawStyle, SoEnvironment, SoEventCallback, SoExtSelection, SoFaceSet, SoFile, SoFont, SoFontStyle, SoFragmentShader, SoFrustumCamera, SoGeoCoordinate, SoGeoLocation, SoGeometryShader, SoGeoOrigin, SoGeoSeparator, SoGroup, SoImage, SoIndexedFaceSet, SoIndexedLineSet, SoIndexedMarkerSet, SoIndexedNurbsCurve, SoIndexedNurbsSurface, SoIndexedPointSet, SoIndexedShape, SoIndexedTriangleStripSet, SoInfo, SoLabel, SoLevelOfDetail, SoLight, SoLightModel, SoLinearProfile, SoLineSet, SoListener, SoLocateHighlight, SoLOD, SoMarkerSet, SoMaterial, SoMaterialBinding, SoMatrixTransform, SoMultipleCopy, SoNonIndexedShape, SoNormal, SoNormalBinding, SoNurbsCurve, SoNurbsProfile, SoNurbsSurface, SoOrthographicCamera, SoPackedColor, SoPathSwitch, SoPendulum, SoPerspectiveCamera, SoPickStyle, SoPointLight, SoPointSet, SoPolygonOffset, SoProfile, SoProfileCoordinate2, SoProfileCoordinate3, SoQuadMesh, SoResetTransform, SoReversePerspectiveCamera, SoRotation, SoRotationXYZ, SoRotor, SoScale, SoSceneTexture2, SoSceneTextureCubeMap, SoSelection, SoSeparator, SoShaderObject, SoShaderParameter, SoUniformShaderParameter, SoShaderParameter1f, SoShaderParameter1i, SoShaderParameter2f, SoShaderParameter2i, SoShaderParameter3f, SoShaderParameter3i, SoShaderParameter4f, SoShaderParameter4i, SoShaderParameterArray1f, SoShaderParameterArray1i, SoShaderParameterArray2f, SoShaderParameterArray2i, SoShaderParameterArray3f, SoShaderParameterArray3i, SoShaderParameterArray4f, SoShaderParameterArray4i, SoShaderParameterMatrix, SoShaderParameterMatrixArray, SoShaderStateMatrixParameter, SoShaderProgram, SoShape, SoShapeHints, SoShuttle, SoSphere, SoSpotLight, SoSurroundScale, SoSwitch, SoText2, SoText3, SoTexture, SoTexture2, SoTexture2Transform, SoTexture3, SoTexture3Transform, SoTextureCombine, SoTextureCoordinate2, SoTextureCoordinate3, SoTextureCoordinateBinding, SoTextureCoordinateCube, SoTextureCoordinateCylinder, SoTextureCoordinateDefault, SoTextureCoordinateEnvironment, SoTextureCoordinateFunction, SoTextureCoordinateNormalMap, SoTextureCoordinateObject, SoTextureCoordinatePlane, SoTextureCoordinateReflectionMap, SoTextureCoordinateSphere, SoTextureCubeMap, SoTextureMatrixTransform, SoTextureScalePolicy, SoTextureUnit, SoTransform, SoTransformation, SoTransformSeparator, SoTranslation, SoTransparencyType, SoTriangleStripSet, SoUnits, SoVertexAttribute, SoVertexAttributeBinding, SoVertexProperty, SoVertexShader, SoVertexShape, SoWWWAnchor, SoWWWInline, SoPath, SoVRMLAnchor, SoVRMLAppearance, SoVRMLAudioClip, SoVRMLBackground, SoVRMLBillboard, SoVRMLBox, SoVRMLCollision, SoVRMLColor, SoVRMLColorInterpolator, SoVRMLCone, SoVRMLCoordinate, SoVRMLCoordinateInterpolator, SoVRMLCylinder, SoVRMLCylinderSensor, SoVRMLDirectionalLight, SoVRMLDragSensor, SoVRMLElevationGrid, SoVRMLExtrusion, SoVRMLFog, SoVRMLFontStyle, SoVRMLGeometry, SoVRMLGroup, SoVRMLImageTexture, SoVRMLIndexedFaceSet, SoVRMLIndexedLine, SoVRMLIndexedLineSet, SoVRMLIndexedShape, SoVRMLInline, SoVRMLInterpolator, SoVRMLLight, SoVRMLLOD, SoVRMLMaterial, SoVRMLMovieTexture, SoVRMLNavigationInfo, SoVRMLNormal, SoVRMLNormalInterpolator, SoVRMLOrientationInterpolator, SoVRMLParent, SoVRMLPixelTexture, SoVRMLPlaneSensor, SoVRMLPointLight, SoVRMLPointSet, SoVRMLPositionInterpolator, SoVRMLProximitySensor, SoVRMLScalarInterpolator, SoVRMLScript, SoVRMLSensor, SoVRMLShape, SoVRMLSound, SoVRMLSphere, SoVRMLSphereSensor, SoVRMLSpotLight, SoVRMLSwitch, SoVRMLText, SoVRMLTexture, SoVRMLTextureCoordinate, SoVRMLTextureTransform, SoVRMLTimeSensor, SoVRMLTouchSensor, SoVRMLTransform, SoVRMLVertexLine, SoVRMLVertexPoint, SoVRMLVertexShape, SoVRMLViewpoint, SoVRMLVisibilitySensor, and SoVRMLWorldInfo.

hasMultipleWriteRefs()

SbBool SoBase::hasMultipleWriteRefs ( void ) const

protected

Returns TRUE if this object will be written more than once upon export. Note that the result from this method is only valid during the second pass of a write action (and partially during the COUNT_REFS pass).

incrementCurrentWriteCounter()

void SoBase::incrementCurrentWriteCounter ( void )

static

This API member is considered internal to the library, as it is not likely to be of interest to the application programmer.

isOfType()

SbBool SoBase::isOfType

(

SoType

type

)

const

Returns TRUE if the type of this object is either of the same type or inherited from type.

This is used for runtime type checking and "downward" casting.

Usage example:

void foo(SoNode * node)
{
  if (node->isOfType(SoGroup::getClassTypeId())) {
    SoGroup * group = (SoGroup *)node;  // safe downward cast, knows the type
  }
}

notify()

void SoBase::notify ( SoNotList * l )

virtual

Notifies all auditors for this instance when changes are made.

Reimplemented in SoProfilerStats, SoFieldContainer, SoNode, SoVertexAttribute, SoAsciiText, SoBumpMap, SoImage, SoIndexedLineSet, SoIndexedPointSet, SoMaterial, SoPackedColor, SoSceneTexture2, SoSceneTextureCubeMap, SoText3, SoTexture2, SoTexture3, SoTextureCubeMap, SoVertexProperty, SoVRMLAppearance, SoVRMLBillboard, SoVRMLCollision, SoVRMLElevationGrid, SoVRMLExtrusion, SoVRMLGeometry, SoVRMLGroup, SoVRMLIndexedLine, SoVRMLIndexedLineSet, SoVRMLIndexedShape, SoVRMLLOD, SoVRMLParent, SoVRMLPixelTexture, SoVRMLProximitySensor, SoVRMLScript, SoVRMLShape, SoVRMLSwitch, SoVRMLText, SoVRMLTimeSensor, SoVRMLTouchSensor, SoVRMLTransform, SoVRMLVertexLine, SoVRMLVertexPoint, SoVRMLVertexShape, SoShadowGroup, SoEngine, SoNodeEngine, SoBlinker, SoLevelOfDetail, SoLOD, SoSeparator, SoShape, SoSwitch, and SoVertexShape.

read()

SbBool SoBase::read ( SoInput * in, SoBase *& base, SoType expectedtype )

static

Read next SoBase derived instance from the in stream, check that it is derived from expectedtype and place a pointer to the newly allocated instance in base.

FALSE is returned on read errors, mismatch with the expectedtype, or if there are attempts at referencing (through the USE keyword) unknown instances.

If we return TRUE with base equal to NULL, three things might have happened:

1. End-of-file. Use SoInput::eof() after calling this method to detect end-of-file conditions.
2. in didn't have a valid identifier name at the stream for us to read. This happens either in the case of errors, or when all child nodes of a group have been read. Check if the next character in the stream is a '}' to detect the latter case.
3. A child was given as the NULL keyword. This can happen when reading the contents of SoSFNode fields (note that NULL is not allowed for SoMFNode)

If TRUE is returned and base is not NULL upon return, the instance was allocated and initialized according to what was read from the in stream.

readInstance()

SbBool SoBase::readInstance ( SoInput * in, unsigned short flags )

protectedpure virtual

This method is mainly intended for internal use during file import operations.

It reads a definition of an instance from the input stream in. The input stream state points to the start of a serialized / persistent representation of an instance of this class type.

TRUE or FALSE is returned, depending on if the instantiation and configuration of the new object of this class type went OK or not. The import process should be robust and handle corrupted input streams by returning FALSE.

flags is used internally during binary import when reading user extension nodes, group nodes or engines.

Implemented in SoEngine, SoNodeEngine, SoFieldContainer, SoProtoInstance, SoBaseKit, SoInteractionKit, SoNodeKitListPart, SoBumpMap, SoFile, SoGroup, SoImage, SoNode, SoNormalBinding, SoSeparator, SoShaderObject, SoTexture2, SoTexture3, SoTextureCoordinateBinding, SoTextureCubeMap, SoVertexAttribute, SoWWWInline, SoVRMLBackground, SoVRMLImageTexture, SoVRMLLOD, SoVRMLParent, SoVRMLPixelTexture, SoVRMLSwitch, and SoProto.

readRoute()

SbBool SoBase::readRoute ( SoInput * in )

static

This API member is considered internal to the library, as it is not likely to be of interest to the application programmer.

Reads a (VRML97) ROUTE. We decided to also add support for routes in Coin, as a generic feature, since we think it is nicer than setting up field connections inside the nodes.

ref()

void SoBase::ref

(

void

)

const

Increase the reference count of the object. This might be necessary to do explicitly from user code for certain situations (mainly to avoid premature deletion), but is usually called from other instances within the Coin library when objects are made dependent on each other.

See the class documentation of SoNode for more extensive information about reference counting.

See also

unref(), unrefNoDelete()

removeAuditor()

void SoBase::removeAuditor	(	void *const	auditor,
		const SoNotRec::Type	type )

Remove an auditor from the list. auditor will then no longer be notified whenever any updates are made to this object.

See also

addAuditor()

removeName()

void SoBase::removeName ( SoBase *const base, const char *const name )

static

Removes a name<->object mapping from the global dictionary.

setInstancePrefix()

void SoBase::setInstancePrefix ( const SbString & c )

static

Referenced instances of SoBase are written as "DEF NamePrefixNumber" when exported. "Name" is the name of the base instance from setName(), "Prefix" is common for all objects and can be set by this method (default is "+"), and "Number" is a unique id which is necessary if multiple objects have the same name.

If you want the prefix to be something else than "+", use this method.

setName()

void SoBase::setName ( const SbName & newname )

virtual

Set the name of this object.

Some characters are invalid to use as parts of names for SoBase derived objects, as object names needs to be consistent with the syntax of Inventor and VRML files upon file export / import operations (so one must for instance avoid using special token characters).

Invalid characters will be automatically replaced by underscore characters. If the name starts with an invalid character, the new name will be preceded by an underscore character.

For the exact definitions of what constitutes legal and illegal characters for SoBase names, see the SbName functions listed below.

See also

getName(), SbName::isBaseNameStartChar(), SbName::isBaseNameChar()

setTraceRefs()

void SoBase::setTraceRefs ( SbBool trace )

static

Set to TRUE to activate debugging of reference counting, which could aid in finding hard to track down problems with accesses to freed memory or memory leaks. Note: this will produce lots of debug information in any "normal" running system, so use sensibly.

The reference tracing functionality will be disabled in "release versions" of the Coin library.

shouldWrite()

SbBool SoBase::shouldWrite

(

void

)

Returns TRUE if this object should be written out during a write action. Will return FALSE if no references to this object have been made in the scene graph.

Note that connections from the fields of field container objects is not alone a valid reason for writing out the object – there must also be at least one reference directly from another SoBase (like a parent/child relationship, for instance).

This method will return a valid result only during the second pass of write actions.

startNotify()

void SoBase::startNotify ( void )

virtual

This is the method which starts the notification sequence after changes.

At the end of a notification sequence, all "immediate" sensors (i.e. sensors set up with a zero priority) are triggered.

Reimplemented in SoNode.

staticDataLock()

void SoBase::staticDataLock ( void )

staticprotected

Lock access to static data.

staticDataUnlock()

void SoBase::staticDataUnlock ( void )

staticprotected

Unlock access to static data.

touch()

void SoBase::touch

(

void

)

Force an update, in the sense that all objects connected to this object as an auditor will have to re-check the values of their inter-dependent data.

This is often used as an effective way of manually triggering a redraw by application programmers.

unref()

void SoBase::unref

(

void

)

const

Decrease the reference count of an object. If the reference count reaches zero, the object will delete itself. Be careful when explicitly calling this method, beware that you usually need to match user level calls to ref() with calls to either unref() or unrefNoDelete() to avoid memory leaks.

See also

ref(), unrefNoDelete()

unrefNoDelete()

void SoBase::unrefNoDelete

(

void

)

const

Decrease reference count, but do not delete ourself if the count reaches zero.

See also

unref()

writeFooter()

void SoBase::writeFooter ( SoOutput * out ) const

protected

This method will terminate the block representing an SoBase derived object.

writeHeader()

SbBool SoBase::writeHeader ( SoOutput * out, SbBool isgroup, SbBool isengine ) const

protected

Write out the header of any SoBase derived object. The header consists of the DEF keyword and the object name (if the object has a name, otherwise these will be skipped), the class name and a left bracket.

Alternatively, the object representation may be made up of just the USE keyword plus the object name, if this is the second or subsequent reference written to the file.

If the object has been completed just by writing the header (which will be the case if we're writing multiple references of an object), we return TRUE, otherwise FALSE.

If we return FALSE (i.e. there's more to write), we will increment the indentation level.

See also

writeFooter(), SoOutput::indent()

---

The documentation for this class was generated from the following files:

• SoBase.h
• SoBase.cpp
